AD5040BRJZ-500RL7

IC DAC 14BIT V-OUT SOT23-8

1 review(s) | Add your review

Availability: In stock

Manufacturer: Analog Devices Inc.

SKU: AD5040BRJZ-500RL7

Datasheet:

How many quantities do you need:

Please input your name:

Please input your email:

AD5040BRJZ-500RL7 Description

marking code	Part No.	Manufacturer	Package	Pin	Memo
D4C	AD5040BRJZ-500RL7	ADI	RJ-8	8	14/16位VOUTnanoDAC?转换器，nanoDAC?转换器，

Operating Temperature	-40°C ~ 85°C
Data Interface	SPI, DSP
Differential Output	No
INL/DNL (LSB)	±0.5, ±0.5
Reference Type	External
Mounting Type	Surface Mount
Supplier Device Package	SOT-23-8
Number of Bits	14
Package	Tape & Reel (TR),Cut Tape (CT),Digi-Reel?
Architecture	R-2R
Number of D/A Converters	1
Voltage - Supply, Analog	2.7V ~ 5.5V
Settling Time	4μs (Typ)
RoHS	RoHS
Voltage - Supply, Digital	2.7V ~ 5.5V
Output Type	Voltage - Buffered
