IDH03SG60C

IDH03SG60 - COOLSIC SCHOTTKY DIO

1 review(s) | Add your review

Availability: In stock

Manufacturer: Rochester Electronics, LLC

SKU: IDH03SG60C

Datasheet:

How many quantities do you need:

Please input your name:

Please input your email:

IDH03SG60C Description

marking code	Part No.	Manufacturer	Package	Pin	Memo
D03G60C	IDH03SG60C	INFINEON	PG-TO220-2	2	3nd Generation thinQ!TM SiC Schottky Diode

Capacitance @ Vr, F	60pF @ 1V, 1MHz
Mounting Type	Through Hole
Supplier Device Package	PG-TO220-2-2
Diode Type	Silicon Carbide Schottky
Operating Temperature - Junction	-55°C ~ 175°C
Package	Bulk
Voltage - Forward (Vf) (Max) @ If	2.3 V @ 3 A
Current - Reverse Leakage @ Vr	15 μA @ 600 V
Reverse Recovery Time (trr)	0 ns
Voltage - DC Reverse (Vr) (Max)	600 V
Current - Average Rectified (Io)	3A (DC)
RoHS	RoHS
Speed	No Recovery Time > 500mA (Io)
