LM5106SD

IC GATE DRVR HALF-BRIDGE 10WSON

1 review(s) | Add your review

Availability: In stock

Manufacturer: Texas Instruments

SKU: LM5106SD

Datasheet:

How many quantities do you need:

Please input your name:

Please input your email:

LM5106SD Description

marking code	Part No.	Manufacturer	Package	Pin	Memo
L5106SD	LM5106SD		SDC10A	10	100V Half Bridge Gate Driver with Programmable Dead-Time

Voltage - Supply	8V ~ 14V
Rise / Fall Time (Typ)	15ns, 10ns
Logic Voltage - VIL, VIH	0.8V, 2.2V
Mounting Type	Surface Mount
Driven Configuration	Half-Bridge
Current - Peak Output (Source, Sink)	1.2A, 1.8A
Operating Temperature	-40°C ~ 125°C (TJ)
Package	Tape & Reel (TR),Cut Tape (CT),Digi-Reel?
Channel Type	Synchronous
High Side Voltage - Max (Bootstrap)	118 V
Gate Type	N-Channel MOSFET
Input Type	Non-Inverting
Supplier Device Package	10-WSON (4x4)
Number of Drivers	2
RoHS	RoHS
